    Germany Siemens PLC Control System Intelligent Tube Ice Machine 1000kg - 30000kg

    Ask Lasest Price
    Brand Name : CBFI
    Model Number : TV10-TV300
    Certification : ISO9001, ISO14001
    Price : USD 0-10000000/ Set
    Payment Terms : T/T, L/C, Western Union, MoneyGram
    Supply Ability : 50 sets/Month
    Delivery Time : 40 Days after the payment
    • Product Details
    • Company Profile

    Germany Siemens PLC Control System Intelligent Tube Ice Machine 1000kg - 30000kg

    CBFI Germany Compressor, Germany Siemens PLC Control System Intelligent Tube Ice Making Machine

    Main Features

    1. Ice tube machine for produce food grade ice too, tube ice is edible ice.
    2. Diameter of tube ice we usually design it as 22mm, 28mm, or 35mm, length of ice is about 30mm to 50mm.
    3. Daily capacity of ice tube machine can be from 1ton to 30tons.

    Germany Siemens PLC Control System Intelligent Tube Ice Machine 1000kg - 30000kg


    Working Condition:


    1. Use hot Freon gas to make ice fall off fast with the whole process takes only 150~180 seconds.
    2. After the ice is off, the water of low temperature is used for ice-making, saving energy consumption and increasing the volume of production of ice.
    3. With the unique water distributive pan and air mouth, the water can evenly flow on the tube wall of the evaporator spirally, so it improves the efficiency of heat transfer.
    4. The use of stainless steel SUS304, accords with the health and safety requirements.
    5. The use of air pressure control excludes the risk of rupture of the evaporator tube and the tube ice diameter can be adjusted according to customers' needs.
    6. Adopt the highest quality spare parts of international brands, such as , Danfoss, Siemens, etc.


    ModelIce Making CapacityRated PowerCirculationg Water Pump PowerCooling Water Pump CapacityCooling Fan CapacityIce Cutter MotorMachine DimensionWeight of Machine
    No.Ton/24hKwKwKwKwKwWxHxL(mm)KG
    TV101.04.280.551.10.180.751100x900x1760900
    TV202.07.770.551.50.370.751250x1000x19501200
    TV303.012.331.11.50.560.751400x1100x22001500
    TV505.0211.52.20.751.51600x1400x22501800
    TV10010.029.21.541.51.5

    1200x1200x3100

    2300x1550x1800

    3500
    TV15015.0492.25.51.51.5

    1500x1200x4500

    2700x1950x2250

    4250
    TV20020.058.52.25.52.22.2

    1600x1300x4700

    3100x2200x2250

    6500
    TV30030.087.62.2152.22.2

    3000x2200x2500

    2200x1900x6200

    7200

    Payment and Delivery:

    1. The payment can be T/T, L/C, Western Union/ Money Gram and cash.

    2. Deposit is 30%. Balance is 70%. When we get your deposit, we start to produce the machine. The balance should be paid before shipping.

    3. The delivery time is about 40 days after the deposit.

    4. We can also ship for you if you pay the freight to us.
