    Energy Efficiency 22mm Ice Tube Machine Water Cooling With Condenser

    Ask Lasest Price
    Brand Name : CBFI
    Model Number : TV50
    Certification : ISO, CE, BV, SGS
    Price : USD10 - USD999999
    Payment Terms : Western Union, L/C, T/T, MoneyGram
    Supply Ability : 60-70 set per month
    Delivery Time : 30 work days
    • Product Details
    • Company Profile

    Energy Efficiency 22mm Ice Tube Machine Water Cooling With Condenser


    CBFI Stainless Steel 5000kg Daily Capacity Tube Ice Making Machine Professional In Philippines


    Product Description

    1. Our ice is edible.
    2. Diameter of tube ice we usually design is 22mm, 28mm, or 35mm,
    Length of ice is about 30mm to 50 mm.

    3. Daily capacity of ice tube machine can be from 1ton to 50tons.
    4. Tube ice macine save space, high efficiency heat exchange, and energy saving, so it is widely favored by market.
    Energy Efficiency 22mm Ice Tube Machine Water Cooling With Condenser
    Tube ice machine for acctually use:
    Application:
    1. It can be eaten directly
    2. It can be used to freeze drinks
    3. Mix wines
    4. Cool food stuffs
    5. Make ice pastries and keep fresh

    6. It is widely used in restaurants, cold drink stores, bars, hotels and so on.


    Machine operating condition:
    1. water temperature: 28Centi degree,
    2. evaporate temperature:-12Centi degree,
    3. condensing temperature: 40Centi degree,
    4. reference valve under 50Hz power supply.
    Real production of machine will change a little according to change of water
    temperature and ambient temperature.



    Tube ice machine features
    1. Perfect design: adopt 3D simulation assembly, compact structure,easy to operate and maintain
    2. healthy material: all the metal of the ice-making machine that will touch with water are SUS304,impurities and metal ions that effect transparent function was discharged from circulating bin during the end of each cycle of ice making.
    3. Efficient performance: ice maker adopt special alloy material and with special heat treatment, make the ice maker with best thermal performance.
    4. Fully automatical system: PLC system controls the whole ice making process.
    Tube ice maker machien technical parameters:

    Energy Efficiency 22mm Ice Tube Machine Water Cooling With Condenser


    1 ton to 30 tons parameters
    ItemCompressorWater circulating pumpIce cutterCooling towerWater pump
    Cooling capacityPowerPowerPowerFan Motor PowerPower
    1 ton17.8 KW7.2 KW0.37 KW0.75 KW0.18 KW1.1 KW
    2 tons22.3 KW7.9 KW0.55 KW0.75 KW0.37 KW1.5 KW
    3 tons30.1kw10.6 kw1.1 KW0.75 kw0.56 KW1.5 KW
    5 tons60.2 kw21 kW1.5 KW1.5 KW0.75 kw2.2 KW
    10 tons83.3 kW29.2 kW1.5 KW1.5 KW1.5 KW4 kw
    15 tons139 kw49 kW2.2 KW1.5 kw1.5 kw5.5 kw
    20 tons166.6 kw58.5 kw2.2 kw2.2 kw2.2 kw5.5 kw
    30 tons249.9 kw87.6 kw2.2 kw2.2 kw2.2 kw7.5 kw



    Note:
    The above information based on water cooling condenser.
    Size of machine is the same with the size before
    installation.
    It didn’t mention size of cooling tower, because cooling tower usually install in the outside.


    Our Services

    1. We have a large after-sale service team. All the technicians are very experienced, they always go to different countries to serve customers like you.

    2. We can provide you with the design drawing and our technicians can install the machine for you.
    3. The warranty of the whole machine is 12 months.

    Energy Efficiency 22mm Ice Tube Machine Water Cooling With Condenser

    Packaging & Shipping

    1. Standard wooden case.
    2. Whole set of ice machine contain: ice machine, cooling tower, water pump, water pipes and water pipe fittings.
    3. Machine come into use, customer only need prepare power for the machine.
    4. All required components for installing the machine will be provided by us.

    FAQ

    1. The payment can be T/T,L/C,Western Union, Money Gram and in Cash.
    2. The deposit is 30%, after we receive your deposit, we will start to produce the machine for you. The balance 70% should be paid before shipping.
    3. The delivery time normally is 30 days after receive the deposit.
    4. If necessary, we will arrange the shipping for you.


    some questions and answers here:

    1. Q: are you add refrigerant in the ice machine?
    A: yes, the machine is full of refrigerant, once with water and electric it can work. yes, ice machine leaves factory with carefully examination after it was produced for 3 to 5 days. And when we install them at customer’s factory, we retest the ice machines.

    2. Q: do you test the ice machine in your factory?
    A: yes, ice machine leaves factory with carefully examination after it was produced for 3 to 5 days. And when we install them at customer’s factory, we retest the ice machines.

    3. Q: can you load ice machine into container?
    A: we have containerized ice block machine. Our export ice machine is designed based on the standard of container, it is easily to load. The 25kg ice of 10tons can load in container of 40 feet. for domestic ice machine of over 12 tons per day, we design based on the standard of truck, which can easily drive into your factory.

    4. Q: all your ice machine is based on 380V 50HZ power requirement? Do you have the right power requirement for abord? Such as 440V 60HZ or 220V three phase that suitable for America?
    A: our ice machine and power,voltage can suitable for your country, please make the power requirement be clear in your order.

    Energy Efficiency 22mm Ice Tube Machine Water Cooling With Condenser
