    Water Cooling Square Cube Ice Making Machine 20 Ton / 24 Hours

    Ask Lasest Price
    Brand Name : CBFI
    Model Number : CV Series
    Certification : CE, ISO
    Price : negotiation
    Delivery Time : 30 work days
    Payment Terms : T/T, Western Union, MoneyGram, L/C
    Supply Ability : 60 sets per month
    • Product Details
    • Company Profile

    Water Cooling Square Cube Ice Making Machine 20 Ton / 24 Hours

    Water Cooling Cube Ice Making Machine Competitive and Reliable Performance


    Water-cooled ice machines are reliable and competitive in terms of their performance. These machines are designed to produce ice efficiently while consuming less energy. With a water-cooled system, the ice machine works by circulating water over a condenser to remove heat generated during the ice-making process.


    One of the significant benefits of a water-cooled ice machine is its reliability. Unlike air-cooled systems, water-cooled machines can operate in warm and humid climates without reducing their efficiency. They are not influenced by external temperature changes and can operate continuously without overheating.


    Moreover, water-cooled ice machines are more durable and long-lasting in comparison to air-cooled machines. The water-cooling process ensures that the machine operates at a consistent temperature, which reduces the likelihood of parts wearing out quickly. This increases the lifespan of the machine and saves the owner from spending on repairs or purchasing a new machine altogether.


    Water-cooled ice machines also have a higher production capacity than air-cooled machines. They can produce more ice in a shorter period, which makes them ideal for commercial applications such as restaurants, supermarkets, and bars. Additionally, they are more energy-efficient than air-cooled systems, which can save business owners money in the long run.


    Another advantage of using a water-cooled ice machine is that it eliminates the need for large fans to circulate air. This makes them quieter than air-cooled machines and reduces the amount of space needed to accommodate the machine. This also means that the machine can be placed in a tighter space, allowing for more efficient use of floor space.


    Large capacity cube ice machine for hotels & restaurants paremeters
    Model Parameters
    CV 1000
    CV 2000
    CV 3000
    CV 5000
    CV 10000
    CV 20000
    Daily output (T/24 h)
    1
    2
    3
    5
    10
    20
    Compressor Power
    4.34 kw
    7.88 kw
    10.58 kw
    21 kw
    42 kw
    73.5 kw
    Fan Power of Cooling Tower
    0.18 kw
    0.37 kw
    0.56 kw
    0.75 kw
    1.5 kw
    2.2 kw
    Cooling Pump Power
    1.1 kw
    1.5 kw
    1.5 kw
    2.2 kw
    4 kw
    5.5 kw
    Unit Size
    L (mm)
    1800
    1630
    1980
    2890
    5730
    7100
    W (mm)
    1000
    1600
    1630
    1780
    1780
    2250
    H (mm)
    1700
    1706
    1860
    1860
    2130
    2300
    Unit N.W. (kg)
    800
    1000
    1200
    1600
    3000
    5000
    1. Size of cube ice: 22*22*22 mm ; 29*29*22 mm ; 38*38*22 mm.
    2. Compressor brand: Bizter / Frascold; refrigerant: R507/ R404A;Cooling Method: Water Cooling / Air Cooling.
    3. Power Supply: Voltage 380V/3P/50Hz (For non-standard voltage, unit configuration needs to be calculated separately).
    4. Operating Conditions: T(water supply):20 ℃, T(ambient):32 ℃, T(condensing): 40 ℃, T(evaporating):-10 ℃.
    5. Note: The actual ice production varies due to the influence of the water supply temperature and ambient temperature.
    6. The final interpretation of the above mentioned parameter is in Icesource, there will be further notice, if there any technical change.
