    5 Tons Ice Block Machine With / Copeland / Hanbell Compressor

    Ask Lasest Price
    Brand Name : CBFI
    Model Number : BBI-300
    Certification : CE / ISO/3C
    Price : negotiation
    Payment Terms : T/T or western Union or moneygram
    Supply Ability : 30 sets per month
    Delivery Time : 30 working days after received your deposit
    • Product Details
    • Company Profile

    5 Tons Ice Block Machine With / Copeland / Hanbell Compressor

    / Copeland / Hanbell Compressor Ice Block Machine 5 Tons With Block Ice


    Industrial Ice Block Maker Making Machine price

    1.Daily capacity: 1 to 100tons

    2.Ice Size: 5kg,10kg,25kg,50kg… or customized size.

    3.Application:

    (1)Cooling.(2)Food preservation.(3)Distance transportation.

    (4) Fresh keeping for aquatic products.(5) Ice factory of the ports and docks.

    (6)Special areas of cooling.

    5 Tons Ice Block Machine With / Copeland / Hanbell Compressor

    Features:

    • Energy-saving: 74km.h/ton
    • High Productivity: 1-120tons daily
    • Long Service life: More than 10 years
    • Certificate: CE
    • Can be Customized

    Hosepipe installation: Installation easier and simple.


    Parameter

    model

    Ice

    making

    capacity

    Rated

    power

    Agitator

    power

    Cooling

    pump

    power

    Cooling

    fan

    power

    Machine

    dimension

    Weight

    of

    machine

    NO.TON/24HKWKWKWKWW X H X L(mm)KG
    BBI101.03.921.51.10.182600*1400*830990
    BBI151.55.221.51.10.182800*1810*10501000
    BBI202.06.421.51.50.373600*1700*7951100
    BBI303.08.662.21.50.564320*1670*7951300
    BBI505.013.072.22.20.756690*1880*8001700
    BBI606.016.7932.20.757000* 1880*8501900
    BBI808.019.61441.58490 * 2000 *13702300
    BBI10010.024441.59000 * 2100 *13002700

    normally daily capacity specification (from 1 ton to 100 tons )

    Water supply temperature 23°C,

    evaporating temperature -18°C,

    condensing temperature 40°C, ( valve under 50Hz power supply.

    real values may vary due to different water supply temperature and ambient temperature ).


    5 Tons Ice Block Machine With / Copeland / Hanbell Compressor5 Tons Ice Block Machine With / Copeland / Hanbell Compressor


    Block Ice Making Machine

    1. Cooling.

    2. Food preservation.

    3. Distance transportation.

    4. Fresh keeping for aquatic products.
    5. Ice factory of the ports and docks.
    6. Special areas of cooling.


    Ice Moulds

    1.The size can be 5kg,10kg,25kg,50kg... or customized size.

    2.Stainless Steel 304 materials making block ice clean.
    3.Special groove decompress design increases service life.


    Coil Pipe Evaporator
    1.Unique oil return design ensures the compressor life.

    2.Three anti-corrosive processing makes sure the quality.

    3.Large touch area with brine leads to better heat exchange effect.
    4.Hydraulic pipe bending technology make sure that the possibility of leakage possibility is tiny.


    5 Tons Ice Block Machine With / Copeland / Hanbell Compressor5 Tons Ice Block Machine With / Copeland / Hanbell Compressor


    Why chooose CBFI Block Ice Maker Making Machine ?

    1. More "fool" typed installation, less space needed and convenient to move.

    2.Energy saving, ice making power consumption had declined from 110kW·h to 74kW·h/ton block ice.

    3.Adopting coil pipe evaparator, no need worrying about ice forming inside the evaporator to break down it.

    4. Using agitator with better heat exchange effect, no need worrying about the high cost for repairing the water pump.
