    R507 Air Cooled 10 20 30 60 Ton Flake Ice Machine Commercial And Industral

    Ask Lasest Price
    Brand Name : CBFI
    Model Number : BF1000-BF60000
    Certification : ISO, CE, SGS, BV
    Price : negotiation
    Payment Terms : Western Union, L/C, T/T, MoneyGram
    Supply Ability : 60 set per month
    Delivery Time : 30 work days
    • Product Details
    • Company Profile

    R507 Air Cooled 10 20 30 60 Ton Flake Ice Machine Commercial And Industral

    R507 Air Cooled 10 20 30 60 Ton Flake Ice Machine Commercial And Industral
    Flake Ice Machine Product Description

    Flake ice machine is a kind of ice machine, generally mostly industrial ice machine. The ice produced is in the form of flakes. Flake ice can be made from fresh water or salt water. Flake ice is thin, dry, loose white ice with a thickness of 10 mm to 15 mm, an irregular plane shape, and a diameter of about 12 to 45 mm. Flake ice has no sharp edges and corners, and will not stab frozen objects. It can enter the gap between the objects to be cooled, reduce heat exchange, maintain the temperature of ice, and have a good moisturizing effect. Flake ice has an excellent cooling effect. The biggest feature of the flake ice machine is that the ice is fast, the amount is large, and the output is directly crushed ice. Therefore, it is mainly used in various large-scale refrigeration facilities, food quick-freezing, concrete cooling and so on.


    Flake Ice Maker Working Principle


    The water enters the water distribution tray from the water inlet of the evaporator of the flake ice machine, and the water is evenly sprinkled on the inner wall of the evaporator through the sprinkler pipe, gradually forming a water film, and the water film and the refrigerant in the evaporator flow channel are heated. Exchange, the temperature drops rapidly, and a thin layer of ice is formed on the inner wall of the evaporator. Under the extrusion of the ice blade, it is broken into pieces of ice, and falls into the ice storage from the ice drop port. The water outlet returns to the cold water tank and passes through the cold water circulation pump.


    Flake Ice Making Machine Product Parameter

    Flake Ice Machine Parameters
    ModelDaily output
    (T/24h)
    Cooling
    Method
    Compressor
    Power
    Fan Power for Cooling TowerCooling Pump
    Power
    Unit size (L*W*H mm)Unit N.W.
    (kg)
    BF5000.5Air4.1kw1280*800*800160
    BF10001Air7.44kw1320*900*900210
    BF20002Air10kw1750*1100*1050360
    BF30003Water8.45kw0.37kw1.5kw1500*1250*12601000
    BF50005Water13.49kw0.75kw2.2kw1900*1500*14701100
    BF60006Water19.94kw0.75kw2.2kw1900*1500*14701100
    BF80008Water24.2kw1.5kw2.2kw2400*1900*18601300
    BF1000010Water33.8kw1.5kw4kw2500*2000*18601500
    BF1500015Water44.5kw1.5kw4kw3350*2150*19603200
    BF2000020Water64kw1.5kw5.5kw3400*2220*22304200
    BF2500025Water76.5kw2.2kw5.5kw3700*2250*25104600
    BF3000030Water93.7kw2.2kw7.5kw4700*2250*25205000
    BF4000040Water118kw2.2kw7.5kw5000*2300*27007500
    ♦ Compressor Brand: / Hanbell; Refrigerant: R507/R404A;
    ♦ Power Supply: Voltage 380V/3P/50Hz (For non-standard voltage, unit configuration needs to be calculated separately).
    ♦ Operating Conditions: T(water supply) : 20 ° C, T(ambient) : 32 ° C, T(condensing) : 38 ° C,T(evaporating):-20℃.
    ♦ (Note: The actual ice production varies due to the influence of water supply temperature and ambient temperature.)
    ♦ (The final interpretation of the above metioned parameters is in Icesource, there will be no further notice, if there is any technical change.)

    Application of flake ice machine:


    Flake ice has a flat shape and a larger surface area than other types of ice, so the cooling effect is better. The normal surface area of one ton of flake ice is 1579 square meters, and the particle ice can only provide 395 to 1294 square meters, so the cooling efficiency of flake ice is 2-5 times higher than that of particle ice.
